Standard RIP Kit for 2500 4WD/AWD Sprinter

Price

$0.00

  • FOX 2.0 Rear Shocks
  • Custom rear leaf springs rated for your axle weight
  • Coil assist springs to support front-end performance
  • Complete installation hardware included

Rear Spring Rate

Wheel Hardware

DESCRIPTION

Confidence in Your Sprinter on Any Terrain

FOX 2.0 Rear Shocks + Custom Leaf Springs + Coil Assist Kit

The Agile Offroad RIP Kit is the proven fix for the harsh, unsettled ride of the 4WD/AWD Sprinter 2500. Tuned FOX 2.0 Performance shocks, custom-rate leaf packs, and Agile’s coil assist kit work together to smooth out potholes, washboard roads, and mountain passes—without killing highway comfort. The result: a Sprinter that’s more stable, more controlled, and ready for vanlife, towing, or trail use. 100% bolt-on, no fabrication required.

Benefits

  • Reduces body roll & rear-end bounce

  • Enhances control on dirt and pavement

  • Smoother ride over rough terrain

  • Increases suspension travel & articulation

  • Bolt-on kit = no cutting, no welding

Tuned Components

  • Custom Leaf Springs – Restores suspension geometry, levels under load, and improves stability when hauling or towing.

  • Coil Assist Kit – Reduces dive and bottom-outs, keeping the front planted and controlled.

  • Rear Brake Line Cover – Shields critical brake lines from rocks and debris.

  • FOX 2.0 Shocks – Sprinter-specific damping for consistent, fade-free performance.

Specifications

  • Fitment: Sprinter 2500 4WD / AWD

  • Lift Height: ~2″

  • Front: Agile Coil Assist Kit

  • Rear: FOX 2.0 shocks + custom leaf springs

  • Install: 100% bolt-on

  • Config: Weight-based spring setup required

  • Shipping: Freight (oversized components)

Full Kit Includes

  • FOX 2.0 Rear Shocks (AOR108)

  • Coil Assist Kit (AOR70X)

  • Coil Covers (SSCOIL2.5PS)

  • Rear Brake Line Cover (AOR259)

  • Leaf Spring U-Bolts (AOR274)

  • Leaf Springs (AO-S6S-X)

  • Wheel Spacer Kit (AOR000X)

Options

  • Model Year: NCV3 (2007–2018) | VS30 (2019+)

  • Spring Rate: 4200 lbs | 4700 lbs | 5400 lbs

  • Wheel Type: Aftermarket Alloy – 20mm | MB Factory Alloy – 16mm | MB Factory Steel – 20mm

If you want your Sprinter to stay composed on highways, trails, or heavy loads, the Agile Offroad RIP Kit delivers. Confidence you can feel—every mile, every road.
